20mm Cold-Moulded Rubber Gym Tiles 1m x 1m
- Precision cold-moulded for straight, tight joints and a flawless finish
- Up to 65dB sound reduction, house-tested in a real home gym
- Rated to 400kg: built for racks, benches, dumbbells and machines
- Full 1m x 1m tiles: 1 tile per m², fewer joins, faster installs
How many do I need?Enter your room size and we'll set the quantity and ramp edges
-
Free UK deliveryMainland UK, no minimum order
-
3-Year WarrantySee what's covered
-
14-day returnsUnused product
-
Secure checkoutEncrypted payment
Not sure which tile? Compare the range
Prices include VAT and free UK mainland delivery.
| Product | Thickness | Size | Key feature | Price per m² | Rating |
|---|---|---|---|---|---|
 EVA Foam Gym Tiles
|
12mm | 610 × 610mm | Anti-Fatigue Interlocking Mats | £21.50 | ★ 5.0 (34) |
 12mm Interlocking Rubber Gym Tiles 1m x 1m
|
12mm | 1m × 1m | Blue & White Fleck | £39.99 | ★ 5.0 (28) |
 16mm Interlocking Rubber Gym Tiles
|
16mm | 500 × 500mm | 70% Impact Absorption | £51.96 | ★ 5.0 (37) |
 17mm Interlocking Rubber Gym Mats
|
17mm | 3ft × 3ft | 200kg Drop Rated | £53.82 | ★ 5.0 (37) |
 DuraSof 18mm Interlocking Rubber Gym Tiles 1m x 1m
|
18mm | 1m × 1m | Checker-Plate Anti-Slip | £54.00 | — |
 20mm Interlocking Rubber Gym Tiles 1m x 1m
|
20mm | 1m × 1m | 400kg Rated | £55.00 | ★ 5.0 (25) |
 20mm Cold-Moulded Rubber Gym Tiles 1m x 1mYou're viewing this
|
20mm | 1m × 1m | 400kg Rated | £55.00 | ★ 5.0 (25) |
 30mm Heavy Duty Rubber Gym Tiles
|
30mm | 1m × 1m or 500mm | 600kg Rated | £75.00 | ★ 5.0 (31) |
 30mm Acoustic Rubber Gym Tiles
|
30mm | 1m × 1m or 500mm | Up to 75dB Drop-Noise Reduction | £75.00 | ★ 5.0 (30) |
Premium 20mm cold-moulded black rubber gym tiles, now in a full 1m x 1m size. Each tile is formed in a precision steel mould, so every edge is straight and every tile is exactly the same size. They butt together tightly for a seamless-looking black floor that looks professionally fitted from the first row to the last.
Rated to 400kg and house-tested to give up to 65dB of sound reduction, these tiles protect your floor and keep training noise down. One tile covers exactly 1m², so planning is simple and installs are fast. Free UK mainland delivery, same-day dispatch before 2pm and a 3-year warranty.
- Precision cold-moulded: straight edges and tight, near-invisible joints
- Up to 65dB sound reduction: house-tested in a real home gym
- Rated to 400kg: built for racks, benches, dumbbells and plate-loaded machines
- Full 1m x 1m tiles: 1 tile per m², fewer joins and faster installs
- Low odour: premium German polyurethane binder, VOC tested
Precision Cold-Moulded for a Flawless Finish
Instead of being cut from a large pressed sheet, each tile is formed individually in a precision steel mould. That gives consistent dimensions to within ±0.5% on length and ±1% on thickness, so edges meet cleanly, joints stay tight and the floor stays square across the whole room. The result is a smooth, even black surface with the premium look of a professionally fitted commercial floor.
Big 1m x 1m Tiles: Fewer Joins, Faster Installs
The full square-metre format means fewer joins across your floor, a cleaner look and much quicker installation. Measuring up is easy too: your floor area in m² is your tile count. Lay them in a straight grid for a clean, modern look, or offset each row by half a tile for a brick-bond pattern.
Quieter Training: Up to 65dB Sound Reduction
House-tested in a real property under typical gym use, these tiles deliver up to 65dB of sound reduction. The dense 950 kg/m³ rubber absorbs the thud of weights and machines, which makes them a great choice for upstairs home gyms, flats, garden rooms and commercial studios with neighbours.
Built for Heavy Training: Rated to 400kg
At 20mm thick and around 19kg per tile, they give a firm, stable base for squat racks, benches, dumbbell areas and plate-loaded machines, while protecting your subfloor from weights and equipment. The R10 textured surface (Class DS to EN 14041) gives sure footing in dry and high-sweat sessions.
Low-Odour, Certified Quality
The tiles are bonded with a premium German polyurethane binder and independently VOC tested, making them well suited to enclosed home gyms and studios. They are CE marked, REACH compliant and made to ISO 9001, ISO 14001 and ISO 45001 managed standards.
Where to Use 20mm Cold-Moulded Gym Tiles
- Home gyms and garden rooms: a premium, quiet floor that looks built-in
- Garage gyms: lays straight onto concrete and stays stable from -30°C to +80°C
- PT studios and boutique gyms: a sleek black floor that impresses clients
- Squat racks, benches and dumbbell areas: rated to 400kg
- Commercial weight rooms and hotel gyms: CE, REACH and ISO certified
- Upstairs rooms and flats: up to 65dB sound reduction
- Functional training and cardio zones: firm, non-slip and easy to clean
Why Customers Choose Gym Flooring UK
- Rated 5.0 by our customers: trusted by home gyms, studios, schools and commercial gyms
- Free samples: feel the cold-moulded finish before you order
- Expert advice: call 01282 277 710 or WhatsApp us for help planning your floor
- 3-year warranty: see what's covered
- Trade pricing: bulk quotes for gyms, studios and developers, usually within 24 hours
| Thickness | 20mm |
|---|---|
| Tile size | 1000mm x 1000mm (1m x 1m) |
| Coverage | 1m² per tile |
| Tile weight | Approx. 19kg |
| Colour | Black |
| Material | High-density SBR rubber with German polyurethane binder |
| Manufacture | Precision cold-moulded |
| Density | 950 kg/m³ |
| Load rating | 400kg |
| Sound reduction | Up to 65dB (house-tested) |
| Dimensional tolerance | Length ±0.5%, thickness ±1% |
| Tensile strength | 1.38 N/mm² (DIN 53455) |
| Slip resistance | R10 (DIN 51130), Class DS (EN 14041) |
| Antistatic | -0.7 kV |
| Abrasion resistance | Tested to EN ISO 5470 |
| Fire rating | B2 |
| Thermal conductivity | 0.17 W/(mK) (EN 12667) |
| Temperature range | -30°C to +80°C |
| UV resistance | UV-resistant (EN 423) |
| Edge profile | Straight butt joint |
| Installation | Loose-lay, no adhesive |
| Certifications | CE, REACH, VOC tested, ISO 9001:2015, ISO 14001:2015, ISO 45001:2018 |
| Warranty | 3 years |
| SKU | GFUK-TF20-01 |
How Many Tiles Do I Need?
Each tile covers exactly 1m², so your tile count equals your floor area in square metres. Add 5–10% for cuts around walls and doorways. The How many do I need? calculator at the top of the page works it out for you.
| Space | Area | Tiles to order |
|---|---|---|
| Rack area 2m x 2.5m | 5m² | 6 tiles |
| Spare room gym 3m x 3m | 9m² | 10 tiles |
| Single garage 2.5m x 5m | 12.5m² | 13–14 tiles |
| Double garage 5m x 5m | 25m² | 26–28 tiles |
Installation
- Prepare the subfloor: any clean, dry, level hard floor, including concrete, screed, timber or existing solid flooring.
- Choose your layout: straight grid, or brick-bond by offsetting each row by half a tile.
- Butt the tiles together: start from your straightest wall and press each tile firmly against its neighbours.
- Cut to fit: score firmly with a sharp utility knife along a straight edge and snap.
- Train straight away: no adhesive, no curing and no drying time.
The weight of each tile and the tight, precise joints hold the floor in place without glue. For permanent commercial installations, adhesive can be used. Ask our team for advice.
Free UK mainland delivery on every order. Orders placed before 2pm Monday to Friday are dispatched the same day. Smaller orders ship by courier and larger orders are palletised for safe delivery. Unused tiles can be returned within 14 days.
What does cold-moulded mean?
Each tile is formed individually in a precision steel mould rather than cut from a larger sheet. That makes every tile the same size with straight edges, so joints stay tight and the floor looks professionally fitted.
How many tiles do I need?
Each tile is 1m x 1m, so your tile count equals your floor area in m². Add 5–10% for cuts. For example, a 3m x 3m room is 9m², so order about 10 tiles.
Do they interlock?
No, and that's by design. The straight, precision-moulded edges butt tightly together for near-invisible joints. The weight of each tile keeps the floor firmly in place.
How heavy is each tile?
About 19kg. That weight is what keeps the floor stable without glue, and most people can carry and position a tile on their own.
Will they reduce noise?
Yes. House-tested under typical gym use, they give up to 65dB of sound reduction, ideal for upstairs gyms, flats and shared buildings.
Do they smell?
They use a premium German polyurethane binder that is independently VOC tested for low emissions, which makes them well suited to home gyms and enclosed studios.
Can I drop weights on them?
They're rated to 400kg and made for dumbbells, kettlebells, racks and machines. For regular overhead barbell drops, our 30mm heavy duty tiles are the best choice.
What floors can I lay them on?
Any clean, dry, level hard floor, including concrete, screed, timber and existing solid flooring.
Can I get a free sample?
Yes. Request a free sample to feel the cold-moulded finish before you order.
Do you offer trade or bulk pricing?
Yes. We supply commercial gyms, PT studios, property developers and leisure facilities across the UK. Send us your floor plan for a bulk quote, usually within 24 hours.
