30mm Heavy Duty Rubber Gym Tiles
- 600kg rated with 200kg+ overhead drops: our heaviest-duty gym tile
- Up to 70dB sound reduction for barbell drops and heavy lifting
- 90% impact absorption protects concrete, barbells and bumper plates
- 30mm high-density rubber, interlocking on all sides, no glue needed
How many do I need?Enter your room size and we'll set the quantity and ramp edges
-
Free UK deliveryMainland UK, no minimum order
-
3-Year WarrantySee what's covered
-
14-day returnsUnused product
-
Secure checkoutEncrypted payment
Not sure which tile? Compare the range
Prices include VAT and free UK mainland delivery.
| Product | Thickness | Size | Key feature | Price per m² | Rating |
|---|---|---|---|---|---|
 EVA Foam Gym Tiles
|
12mm | 610 × 610mm | Anti-Fatigue Interlocking Mats | £21.50 | ★ 5.0 (34) |
 12mm Interlocking Rubber Gym Tiles 1m x 1m
|
12mm | 1m × 1m | Blue & White Fleck | £39.99 | ★ 5.0 (28) |
 16mm Interlocking Rubber Gym Tiles
|
16mm | 500 × 500mm | 70% Impact Absorption | £51.96 | ★ 5.0 (37) |
 17mm Interlocking Rubber Gym Mats
|
17mm | 3ft × 3ft | 200kg Drop Rated | £53.82 | ★ 5.0 (37) |
 DuraSof 18mm Interlocking Rubber Gym Tiles 1m x 1m
|
18mm | 1m × 1m | Checker-Plate Anti-Slip | £54.00 | — |
 20mm Interlocking Rubber Gym Tiles 1m x 1m
|
20mm | 1m × 1m | 400kg Rated | £55.00 | ★ 5.0 (25) |
 20mm Cold-Moulded Rubber Gym Tiles 1m x 1m
|
20mm | 1m × 1m | 400kg Rated | £55.00 | ★ 5.0 (25) |
 30mm Heavy Duty Rubber Gym TilesYou're viewing this
|
30mm | 1m × 1m or 500mm | 600kg Rated | £75.00 | ★ 5.0 (31) |
 30mm Acoustic Rubber Gym Tiles
|
30mm | 1m × 1m or 500mm | Up to 75dB Drop-Noise Reduction | £75.00 | ★ 5.0 (30) |
30mm heavy duty rubber gym tiles, built for the hardest-hitting training there is: Olympic lifting, CrossFit and dedicated barbell drop zones. At 30mm thick and over 1,000 kg/m³ density, this is our heaviest-duty gym tile. It's rated to 600kg, tested with 200kg+ overhead barbell drops, and gives up to 70dB of sound reduction to keep heavy sessions quiet.
Choose full 1m x 1m tiles for fast whole-room installs or 500mm x 500mm tiles for lifting platforms and tight spaces, then finish exposed edges with matching safety ramp edges. Free UK mainland delivery, same-day dispatch before 2pm and a 3-year warranty.
- 600kg rated: tested with repeated 200kg+ overhead barbell drops
- Up to 70dB sound reduction: quieter lifting for shared buildings, upstairs gyms and home platforms
- 90% impact absorption: protects your concrete, barbells and bumper plates
- 30mm, 1,000+ kg/m³ rubber: firm, stable footing under maximal lifts
- EN 13893 slip rated, CE and REACH compliant: ready for commercial facilities
600kg Rated: Built for Overhead Drops
The snatch, the clean and jerk and a missed heavy deadlift put more force through a gym floor than anything else in training. These 30mm tiles are engineered for exactly that. The thick, dense rubber takes the energy of a dropped barbell at the point of contact and spreads it across the tile, so your subfloor stays protected and the bar comes to rest cleanly and predictably.
Rated to 600kg and tested with repeated 200kg+ overhead drops, this is the tile specified for weightlifting clubs, CrossFit boxes, university strength and conditioning rooms and serious home lifting platforms.
Up to 70dB Sound Reduction for Heavy Lifting
Thicker, denser rubber means more of each impact is absorbed before it reaches the building. With up to 70dB of sound reduction, the boom of a dropped barbell becomes a muted thud, ideal for gyms in shared buildings, first-floor studios, garages attached to the house and anywhere with neighbours. Need the absolute quietest floor? Our 30mm acoustic tiles are purpose-built for sound control.
90% Impact Absorption Protects Floors, Bars and Plates
The 30mm SBR rubber compound absorbs 90% of impact energy, protecting concrete and timber subfloors from cracking, extending the life of your barbells and bumper plates, and giving lifters a firm, confident base for every rep. The surface is EN 13893 slip rated for secure footing through sweaty, high-volume sessions.
20mm vs 30mm: Which Tile Do You Need?
| 20mm tile | 30mm heavy duty tile | |
|---|---|---|
| Load rating | 400kg | 600kg |
| Overhead barbell drops | Controlled lowering | 200kg+ drops from full extension |
| Sound reduction | Up to 65dB | Up to 70dB |
| Impact absorption | High | 90% |
| Best for | Free weights, racks, home and commercial gyms | Olympic lifting, CrossFit, deadlift and drop zones |
Training mostly with dumbbells and machines? Our 20mm interlocking tiles are a great fit. Dropping loaded barbells? Choose 30mm.
Choose Your Format: 1m x 1m or 500mm x 500mm
Both sizes use the same 30mm rubber and give the same performance. Pick the one that suits your space:
- 1m x 1m tiles: one tile per square metre for the fastest full-room installs in CrossFit boxes, weightlifting halls and commercial weight rooms. The weight of each tile adds stability under repeated drops.
- 500mm x 500mm tiles: four per square metre and easy for one person to handle. Perfect for building a lifting platform, fitting around racks and pillars, or small home gyms.
- Mix and match: 500mm tiles for the platform drop zone, 1m tiles for the surrounding floor.
Where to Use 30mm Rubber Gym Tiles
- Olympic weightlifting: snatch, clean and jerk and overhead drops from full extension
- Powerlifting and deadlift zones: repeated heavy pulls and drops
- CrossFit boxes: all-day barbell, kettlebell and wall-ball work
- Commercial drop zones: free-weight areas where bars are dropped as standard
- Upstairs and shared-building gyms: up to 70dB sound reduction
- Universities, schools and sports clubs: CE and REACH compliant, built for high use
- Garage and home lifting platforms: commercial-grade protection at home
Matching Safety Ramp Edges
Finish every exposed edge with our 500mm bevelled safety ramp edges. They create a smooth transition from the 30mm tile to the surrounding floor and give a clean, professional finish. Select 500mm Safety Ramp Edge in the size options, or let the calculator work out how many you need.
Why Customers Choose Gym Flooring UK
- Rated 5.0 by our customers: trusted by CrossFit boxes, universities, schools and home lifters
- Free samples: feel the 30mm density before you order
- Expert advice: call 01282 277 710 or WhatsApp us for help planning your floor
- 3-year warranty: see what's covered
- Trade pricing: bulk quotes for gyms, clubs and contractors, usually within 24 hours
| Thickness | 30mm |
|---|---|
| Tile sizes | 1000mm x 1000mm and 500mm x 500mm |
| Coverage | 1m² per 1m tile; 0.25m² per 500mm tile |
| Tile weight | Approx. 30kg (1m tile), 7.5kg (500mm tile) |
| Minimum order | 10 x 1m tiles; 500mm tiles and ramps any quantity |
| Colour | Black |
| Material | High-density recycled SBR rubber |
| Density | 1,000+ kg/m³ |
| Load rating | 600kg (estimated from thickness and density) |
| Drop test | Repeated 200kg+ overhead barbell drops |
| Sound reduction | Up to 70dB (estimated) |
| Impact absorption | 90% |
| Slip resistance | EN 13893 |
| Edge profile | Interlocking on all sides |
| Accessories | 500mm bevelled safety ramp edges |
| Installation | Loose-lay, no adhesive |
| Compliance | CE, REACH |
| Warranty | 3 years |
| SKUs | GFUK-30T-01 (1m), GFUK-30T-02 (500mm), GFUK-30T-03 (ramp edge) |
How Many Tiles Do I Need?
For 1m x 1m tiles, your tile count equals your floor area in m². For 500mm x 500mm tiles, multiply the area by 4. Add 5–10% for cuts. The minimum order for 1m x 1m tiles is 10 tiles; 500mm tiles and ramp edges can be ordered in any quantity. The How many do I need? calculator at the top of the page works it all out, including ramp edges.
| Space | Area | 1m x 1m tiles | 500mm tiles |
|---|---|---|---|
| Home lifting platform 2.5m x 2m | 5m² | — | 20–22 |
| Garage gym 3m x 5m | 15m² | 16–17 | 60–66 |
| Double garage 5m x 5m | 25m² | 26–28 | 100–110 |
| CrossFit box zone 8m x 10m | 80m² | 84–88 | 320–352 |
Installation
- Acclimatise: lay the tiles flat in the room for 24 hours so they settle to room temperature.
- Prepare the subfloor: any clean, dry, level hard floor, including concrete, screed or timber.
- Lay and interlock: press the edges firmly together, working row by row. For a drop zone, start at the platform centre and work outwards.
- Cut to fit: a jigsaw gives clean, accurate cuts through 30mm rubber at any angle.
- Finish the edges: fit safety ramp edges on any exposed sides.
No adhesive, no specialist tools and no trades needed. Most floors are laid in a single session, and you can train on them the same day.
Free UK mainland delivery on every order. Orders placed before 2pm Monday to Friday are dispatched the same day. 30mm tile orders are palletised for safe, secure delivery to your kerbside. Unused tiles can be returned within 14 days.
Why choose 30mm tiles for Olympic lifting?
Olympic lifts end with a loaded bar dropped from overhead, the highest-impact load a gym floor takes. 30mm of 1,000+ kg/m³ rubber absorbs 90% of that impact, protecting the subfloor, the bar and the building, while giving lifters a firm, stable base. It's the standard thickness for weightlifting clubs and CrossFit boxes.
What is the drop rating and load rating?
The tiles are tested with repeated 200kg+ overhead barbell drops, and are rated to 600kg based on their 30mm thickness and 1,000+ kg/m³ density. That covers heavy Olympic lifting, powerlifting, racks and plate-loaded machines.
How much noise do they reduce?
Up to 70dB (estimated), making them a great choice for upstairs gyms, shared buildings and garages attached to the house. For maximum sound control, see our 30mm acoustic tiles.
20mm or 30mm: which should I buy?
Choose 30mm if you drop loaded barbells, do Olympic lifts or CrossFit, or want the highest protection and noise reduction. Choose our 20mm tiles for dumbbells, machines and general free-weight training.
Do I need a wooden lifting platform as well?
Not for most gyms. 30mm rubber laid over concrete makes a complete, commercial-grade lifting area on its own. Some competitive lifters like a timber centre panel for feel, and these tiles work perfectly either side of one.
1m x 1m or 500mm x 500mm?
1m tiles are fastest for full rooms and large commercial floors. 500mm tiles are easier to carry, ideal for platforms and tight spaces, and perfect for solo installs. Both give identical performance, and you can mix them.
Is there a minimum order?
The 1m x 1m tiles have a minimum order of 10 tiles (10m²). 500mm x 500mm tiles and safety ramp edges can be ordered in any quantity. Delivery is free to UK mainland addresses on every order.
Do I need ramp edges?
We recommend them on any exposed edge, especially in commercial spaces. They give a smooth transition to the surrounding floor and a neat, professional finish.
Do the tiles need gluing down?
No. The interlocking edges and the weight of each tile hold the floor firmly in place. For permanent commercial installs, ask our team about adhesive options.
Can I use them in a garage?
Yes. They lay straight onto concrete and turn a garage into a proper lifting space. Leave them flat in the room for 24 hours before fitting.
How do I clean rubber gym tiles?
Sweep or vacuum, then mop with warm water and a pH-neutral cleaner. The rubber surface keeps its grip and finish for years.
Can I get a free sample?
Yes. Request a free sample to see and feel the 30mm density before you order.
Do you offer trade or bulk pricing?
Yes. We supply CrossFit boxes, universities, schools, commercial gyms and fit-out contractors across the UK. Send us your floor plan for a bulk quote, usually within 24 hours.
