Thickness Guide
Which thickness do I need?
4–6mm — Cardio, treadmills, yoga. Light floor protection.
10–12mm — Home gyms, dumbbells up to 30kg. Great all-rounder. Most Popular
16–17mm — Commercial gyms, heavy free weights, CrossFit.
20–30mm — Olympic lifting, deadlift platforms. Maximum protection.
Not sure? Ask our experts
✔️ EN 13893 Certified | ✔️ 900 kg/m³ Density | ✔️ 70% Impact Absorption | ✔️ CE & REACH
Commercial-specification 16mm rubber gym tiles for PT studios, leisure centres, corporate wellness spaces and commercial fitness facilities. EN 13893 slip certified, CE and REACH compliant — meeting the safety and compliance requirements of commercial premises.
Why These Tiles?
- ✅ EN 13893 + CE + REACH — satisfies commercial premises certification requirements
- ✅ 900 kg/m³ density — resists permanent compression under heavy static equipment loads
- ✅ Individual tile replacement — reduces long-term maintenance cost vs full floor replacement
- ✅ 65% noise reduction — essential for multi-floor commercial buildings
- ✅ Trade pricing available on orders over 50m² — contact us for a quote within 24 hours
| Specifications | |
|---|---|
| Thickness | 16mm |
| Tile Size | 500mm × 500mm |
| Coverage | 0.25m² per tile (4 tiles = 1m²) |
| Material | Recycled SBR Rubber |
| Density | 900 kg/m³ |
| Slip Resistance | EN 13893 certified |
| Impact Absorption | 70% force reduction |
| Noise Reduction | 65% sound dampening |
| Certifications | CE Certified, REACH Compliant |
| Installation | Puzzle interlock — no adhesive |
How Many Tiles Do You Need?
Each tile covers 0.25m² (500mm × 500mm). You need 4 tiles per m². Measure your room, multiply length × width, add 10% for cuts.
| Room Size | Area | Tiles (inc. 10%) |
|---|---|---|
| 3m × 3m | 9 m² | 40 tiles |
| 4m × 5m | 20 m² | 88 tiles |
| 6m × 6m | 36 m² | 160 tiles |
| 8m × 10m | 80 m² | 352 tiles |
Installation — No Adhesive, No Contractor
Tiles press together with the 4-sided puzzle edge. No adhesive, no tools, no specialist installer. A 20m² floor takes one person approximately 2 hours. Works on concrete, screed or timber. Do not install on carpet.
✔️ Free UK mainland delivery on all orders. Same-day dispatch before 2pm.
See All Rubber Gym Tiles
- 16mm Standard Interlocking Tiles
- 20mm Heavy Duty Tiles — for heavier drops
- 30mm Olympic Lifting Tiles — 200kg+ rated
Frequently Asked Questions
Q: Are these tiles EN 13893 certified — required for commercial gym insurance compliance?
A: Yes. Every tile in this range carries EN 13893 slip resistance certification along with CE marking and REACH compliance. These are the certifications required by most UK commercial gym operators, facility managers, and insurance underwriters for public-access fitness flooring.
Q: How does the 500mm × 500mm tile size work for large commercial gym floors?
A: The 500mm format (4 tiles per m²) gives you excellent layout flexibility across large commercial floor areas. The interlocking system creates seamless joins at scale — ideal for open-plan gym floors, functional training zones, and free weights areas. For very large installations, tiles can be glued to the subfloor for a permanent commercial finish.
Q: What density and impact rating are these tiles — suitable for heavy commercial use?
A: At 900 kg/m³, these are high-density commercial-grade rubber tiles. They deliver 70% impact absorption, making them suitable for free weights zones, functional training areas, and multi-use gym floors in commercial facilities with daily high-traffic use.
Q: Can these tiles be used in commercial spaces with underfloor heating?
A: Yes — rubber gym tiles are compatible with electric underfloor heating systems. The thermal conductivity of rubber allows heat to pass through to the surface without damaging the tiles. Ensure the subfloor temperature does not exceed 27°C at the tile base. Hydronic (wet) UFH systems should be fully balanced before tile installation.
Q: How do I maintain these tiles in a busy commercial gym environment?
A: For high-traffic commercial gyms, sweep daily and damp mop with a gym-safe disinfectant diluted in water. The 900 kg/m³ dense rubber resists liquid ingress, making deep cleaning straightforward. Avoid bleach-based products. Many commercial operators schedule a quarterly deep clean with a rubber floor-specific cleaner.
Q: What's the lead time and can I order in bulk for a full gym fit-out?
A: These tiles are available for bulk commercial orders with competitive pricing for large quantities. Standard orders dispatch within 1–3 working days. For large-scale commercial fit-outs, contact us directly for a project quote — we supply gyms, leisure centres, hotels, and schools across the UK.
Need Advice? Speak to a Flooring Specialist
Not sure which thickness, format or quantity is right for your project? Our flooring specialists are here to help — commercial quotes, sample requests and installation advice all available.
